Development of PCBA single chip microcomputer for induction lamp control board

2021-11-27 10:07:06

Development of PCBA single chip microcomputer for induction lamp control board

Functional specification

1. Human body infrared sensing automatically turns on the light, and the sensing distance is within 12 meters

2. Working mode: when the infrared ray of human body is detected, the LED light will be turned on automatically for 30 seconds. If the infrared of human body is not detected again within 30 seconds, the LED light will be turned off automatically

3. The working power supply only needs a 1.5V alkaline dry battery to work

4. Low standby power consumption and long standby time

5. It has high infrared sensitivity, strong anti-interference and stable and reliable operation

Development of PCBA single chip microcomputer for induction lamp control board

label: Development of induction lamp control board PCBA single chip microcomputer
